MUTOH XPJ-1462UF Flatbed UV Printer
1,420mm (W) x 700mm (D) x 150mm (H) Dual head CMYK+W+V
'Built for Professionals' with made-in-Japan quality.
The XpertJet-1462UF is the perfect balance between productivity and print size. Delivering serious flatbed production without a serious flatbed footprint.
Print Onto Almost Anything
Outstanding Production
Staggered Dual Print Heads
Staggered dual print heads enable higher speed 2-layer printing than single head configurations. It is also ideal for braille and 2.5D structure prints.
Two New UV LED Lamps
Two UV LED lamps located on either side of the head carriage guarantees optimal curing in bi-directional printing.
Production Speed
Media Support
4 Zone Vacuum Table
The table is divided into 4 zones that can be individually controlled to maximise vacuum efficiency.
Table Features
1) Vacuum holes can be used to fix jigs
2) Magnets can be used
3) M4 tapped holes for fixing jigs
4) Etched guide for visual alignment
Auto Head Height Adjustment
The laser sensor automatically detects the thickness of the media and raises the gantry to allow sufficient clearance preventing collisions with the media and protecting the head.
Acceptable media: 1,420mm (W) x 700mm (D) x 150mm (H), up to 50kg/m2
Automatic Nozzle Checking Unit
The automatic nozzle checking unit can optically monitor firing nozzles from the print head, missing nozzles can be detected automatically and nozzle cleaning can be performed reducing operators' workload.
If nozzles are not recovered, the Nozzle Area Select function automatically activates to continue printing.
Nozzle Area Select
Print quality matters! The XpertJet-1462UF have built-in cleaning and maintenance features to ensure the highest quality print results. If however, a nozzle within the print head should clog, Nozzle Area Select allows you to 'turn off' a section of the print head containing the missing nozzle and continue print production with the remaining nozzles.
Test print showing missing nozzle
Print with front portion of the heads
Dedicated nozzle checking area
Perform a manual nozzle check quickly and easily at any time without the need to remove the print job. A dedicated nozzle check area, away from the print area, saves time by allowing media, jig, and head height to remain set and unaltered when a nozzle check print needs to be performed.
MUTOH’s UV LED lamp local dimming control
Multiple effects in one table movement.
The XPJ-1462UF is equipped with segmented UV lamps. Each segment can be individually controlled to enable the production of multiple varnish effects in the same single bed movement such as gloss, semi-gloss, and matte. The result is a substantial productivity boost as well as minimising the risk of dust contamination in the gloss.
Ink Jetting
Curing
Ink Jetting varnish leveling (smoothing)
Curing
